Features
1, the general schedule (4 sets of universal +4 sets of rain) program +6 sets of special time program, each time more programs
Up to 256 timing points. The general schedule program cycle by 7 days, special schedule program according to a specific date
Row. Meet all kinds of time, all kinds of occasions need to use.
2, built-in MP3, FM radio, 6 channel audio source +1 fire input, 32 audio output. 4 Road can be made
Power +1 channel expansion synchronous power supply (short circuit signal) output.
3, 16 fire collection signal input (short circuit signal).
4, microcomputer control, one-touch shuttle, graphical interface, multi-level menu mode of operation.
5, true color 4.3 inch TFT display, Chinese subtitles, work status at a glance.
6, Simplified Chinese, Traditional Chinese, English three language menu to switch freely.
7, built-in 2GB memory, external expansion SD card (up to 8GB), can be directly connected to the PC into MP3 music.
8, can be timed, fixed-point, fixed song, play memory or SD card programs, 8X32 audio matrix, 4 power +1
Show power output.
9, powerful music player, support for MPEG 1/2 Layer 3, WMA, WAV, OGG and other audio
format.
10, a powerful media library features, users can flexibly manage their own music according to their own personality
file.
11, a powerful audio processing capabilities, support for 3D, bass, Microsoft audio and other audio features.
12, HiFi audio decoding performance, sound quality and professional CD comparable.
13, support for high-definition MIC recording, LINE IN recording, FM recording.
14, built-in high-definition FM radio, and supports FM program recording, free to record the selected FM radio
program.
15, can support computer online editing timer program, automatic power supply, audio matrix management.
16, high-precision RTC clock, timing can be accurate to seconds.
17, support fire linkage function, alarm trigger signal input to play the specified music file.
18, all the regular programs at any time easy manual intervention.
19, real-time monitoring of the output sound source, with volume adjustment. (Mechanical volume adjustment).
20,6 Road, ordinary audio +1 fire source input, you can adjust the volume of a separate potentiometer. (machine
Mechanical volume adjustment).
21, using ARM9 platform, 4.3-inch color screen.
Storage Built-in 2G memory or external SD card (up to 8GB)
Support audio formats MP3, WMA, AAC, WAV, APE, FLAC
Radio FM 88-108MHz
Output LINE 500mV Unbalanced
Machine noise ratio ≥85
Machine distortion <0.1% (1KHz)
Frequency response 20Hz-20KHz ± 3dB
Controllable Power Output AC220V / 50Hz (MAX2200W)
Net weight 5Kg
Body size (mm) 485 × 395 × 132 mm
