1, support for 32-channel fire signal acquisition;
2, microcomputer control, sampling fire signal quick and sensitive;
3, support short circuit, 24V trigger (12V-24V) access;
4, accurate alarm partition LED display, alarm area at a glance;
5, support multi-machine cascade, up to 128 fire signals can be collected.
6, can bus network organization, convenient and quick connection.
7, through the bus protocol on-line with the central host to form a strong fire emergency automatic cutting strong broadcast, to improve emergency evacuation capabilities.
Communication interface RJ45
Trigger mode short-circuit trigger / 24V trigger
Input power ~ 220V / 50Hz
Power consumption ≤ 10W
Size 484 × 350 × 88mm
Weight 5.16kg
