1 user-friendly design, 4.3-inch TFT color LCD screen design, easy to operate;
2 built-in powerful and flexible audio matrix, 10 inputs, 16 outputs, can be manually or automatically switch; the district can simultaneously broadcast different programs, without disturbing each other;
3 the input signal with independent volume adjustment, can be applied to different audio equipment;
4 support multi-machine cascade.
Power ~ 220V / 50Hz
Power consumption ≤ 30W
Audio input LINE 10kΩ 0.775V unbalanced
Audio Input Channel 10 Channel Auxiliary Input
Audio output 1kΩ 500mV unbalanced
Audio output channel 16 channels
Frequency response 20Hz ~ 20kHz
Signal to noise ratio ≥ 80dB
Distortion ≤ 0.1%
Communication interface RJ45
Size 484 × 350 × 132mm
Weight 6.5kg
