1, improve the protection circuit: the temperature is too high, the input signal is too large, the load is too heavy, the protection circuit is activated, sound and light alarm is issued at the same time improve the cooling fan speed.
2, balanced input: balanced input can increase the signal transmission distance and improve anti-interference ability of transmission.
3, priority signal input and control: Users can short cut or DC24V strong cut way, the device forcibly switch to the priority signal input emergency broadcast, and at the same time three or four strong cut to the control port.
4, Gain adjustment: The user can adjust the input gain
5, backup power supply system: When the AC power fails, the backup power supply system allows the device to continue to work.
6, comes with timing switch system.
Output power 600W
Frequency response 80Hz-15KHz, ± 3dB
Input 1V / 10 KΩ Balanced
Constant pressure output 70V, 100V
Total harmonic distortion ≤ 1%
Signal to noise ratio ≥ 80dB
Power AC 220V / 50Hz, DC24V
AC power consumption 1200W
Net weight 26.8kg
Gross weight 28.7kg
Body size 482 × 132 × 429mm
Packing size (inner box) 532 × 238 × 498mm
